UC2823BNG4
lmages are for reference only.UC2823BNG4
IC OFFLINE SWITCH MULT TOP 16DIP
Datasheet16-DIP (0.300", 7.62mm)
91,928 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Boost, Buck, Flyback, Forward Topology 1MHz 16-PDIP
UC2823BNG4
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Boost, Buck, Flyback, Forward |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 22V |
| Duty Cycle | 100% |
| Frequency - Switching | 1MHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting |
| Control Features | Frequency Control, Soft Start |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-PDIP |
| Mounting Type | Through Hole |
| Base Product Number | UC2823 |
| Voltage - Start Up | 16 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UC2823BDW | UC2823BN | UC2825BDW | UC2825BDWG4 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SWITCH MULT TOP 16DIP | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SW MULT TOP 16SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
