Low-Side Gate Driver IC Non-Inverting 8-SOIC
UC3714D
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Unitrode |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Driven Configuration | Low-Side |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Voltage - Supply | 7V ~ 20V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | 1A, 2A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 30ns, 25ns |
| Operating Temperature | 0°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | UC3714 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UC3714D | UC3714DP | UC3714DP | UC3714DTR |
| Manufacturer | Texas Instruments | Texas Instruments | Unitrode | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC GATE DRVR LOW-SIDE 8SOIC | IC GATE DRVR LOW-SIDE 16SOIC | BUFFER/INVERTER BASED MOSFET DRI | IC GATE DRVR LOW-SIDE 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tape & Reel (TR) |
