UP2C-220-R
lmages are for reference only.UP2C-220-R
FIXED IND 22UH 2.61A 54 MOHM SMD
DatasheetNonstandard
75,216 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
22 µH Unshielded Drum Core, Wirewound Inductor 2.61 A 54mOhm Nonstandard
UP2C-220-R
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | UNI-PAC™ 2C |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 2.61 A |
| Current - Saturation (Isat) | 2.65A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 54mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.508" L x 0.370" W (12.90mm x 9.40mm) |
| Height - Seated (Max) | 0.205" (5.20mm) |
| Base Product Number | - |
| Product Attribute | |
 |
 |
|
| Part Number | UP2C-220-R | UP2C-100-R | UP2C-101-R | UP2C-150-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | RoHS Compliant | |||
| Description | FIXED IND 22UH 2.61A 54 MOHM SMD | FIXED IND 10UH 3.61A 28.3MOHM SM | FIXED IND 100UH 1.26A 233.1 MOHM | FIXED IND 15UH 3.17A 36.9MOHM SM |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
