Product CatalogPart Number
UPA1760G-E1-A
Manufacturer
RenesasDescription
MOSFET 2N-CH 30V 8A 8SOP
Datasheet
DatasheetPackage
8-SOIC (0.173", 4.40mm Width)
In Stock
27,809 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UPA1760G-E1-A
UPA1760G-E1-A
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 30V 8A (Ta) 2W (Ta) Surface Mount 8-SOP
Quick Inquiry
UPA1760G-E1-A
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Renesas |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 8A (Ta) |
| Rds On (Max) @ Id, Vgs | 26mOhm @ 4A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | 14nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 760pF @ 10V |
| Power - Max | 2W (Ta) |
| Operating Temperature | 150°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) |
| Supplier Device Package | 8-SOP |
| Base Product Number | UPA1760 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute | |
|
 |
|
| Part Number | UPA1601GS-E1-A | UPA1602GS-E1-A | UPA1759G-E1-AT | UPA1763G-E1-A |
| Manufacturer | Renesas | Renesas | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | Not applicable | ROHS3 Compliant |
| Description | MOSFET 7N-CH 30V 0.27A 16SOP | MOSFET 7N-CH 30V 0.43A 16SOP | MOSFET 2N-CH 60V 5A 8PSOP | MOSFET 4.5A |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Tape & Reel (TR) |
