N-Channel 30 V 9.5A (Ta) 2W (Ta) Surface Mount 8-Power TSSOP
UPA1808GR-9JG-E1-A
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Renesas |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 9.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V |
| Rds On (Max) @ Id, Vgs | 17mOhm @ 5A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 660 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 2W (Ta) |
| Operating Temperature | 150°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-Power TSSOP |
| Package / Case | 8-PowerTSSOP (0.173", 4.40mm Width) |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 13 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | UPA1526H-AZ | UPA1556AH(7)-AZ | UPA1556AH-AZ | UPA1559H(1)-AZ |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | Not applicable | ROHS3 Compliant | Not applicable |
| Description | N-CHANNEL POWER MOSFET | N-CHANNEL POWER MOSFET | N-CHANNEL POWER MOSFET | N-CHANNEL POWER MOSFET |
| Series | * | * | * | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
