USB1T1102MHX
lmages are for reference only.USB1T1102MHX
IC TRANSCEIVER HALF 1/1 16MHBCC
Datasheet16-WFQFN Exposed Pad
73,371 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1/1 Transceiver Half USB 2.0 16-MHBCC (3x3)
USB1T1102MHX
| Category | Integrated Circuits (ICs) - Interface - Drivers-Receivers-Transceivers |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | Transceiver |
| Protocol | USB 2.0 |
| Number of Drivers/Receivers | 1/1 |
| Duplex | Half |
| Receiver Hysteresis | 450 mV |
| Data Rate | 12Mbps |
| Voltage - Supply | 5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-WFQFN Exposed Pad |
| Supplier Device Package | 16-MHBCC (3x3) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | USB1T1102MPX | USB1T1103MHX | USB1T1103MHX | USB1T1103MPX |
| Manufacturer | Fairchild Semiconductor | onsemi | Fairchild Semiconductor | Fairchild Semiconductor |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC TRANSCEIVER HALF 1/1 14MLP | IC TRANSCEIVER HALF 1/1 16MHBCC | IC TRANSCEIVER HALF 1/1 16MHBCC | IC TRANSCEIVER HALF 1/1 14MLP |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR) | Bulk | Bulk |
