2.5A Gate Driver Optical Coupling 5300Vrms 1 Channel 8-SMD
VOD3120AB-T
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Optical Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Common Mode Transient Immunity (Min) | 35kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns |
| Pulse Width Distortion (Max) | 70ns |
| Rise / Fall Time (Typ) | 35ns, 35ns |
| Current - Output High, Low | 2.5A |
| Current - Peak Output | 2.5A |
| Voltage - Forward (Vf) (Typ) | 1.37V |
| Voltage - Output Supply | 15V ~ 30V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Supplier Device Package | 8-SMD |
| Approval Agency | CQC, cUL, UL, VDE |
| Base Product Number | VOD3120 |
| Current - DC Forward (If) (Max) | 20 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | VOD3120AB-T2 | VOD3120AB-VT | VOD3120AB-VT2 | VOD3120AD |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 5.3KV 1CH GATE DVR 8SMD | OPTOISO 5.3KV 1CH GATE DVR 8SMD | OPTOISO 5.3KV 1CH GATE DVR 8SMD | OPTOISO 5.3KV 1CH GATE DVR 8DIP |
| Series | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
