SCR 1.2 kV 75 A Standard Recovery Through Hole SUPER-247™ (TO-274AA)
VS-70TPS12PBF
| Category | Discrete Semiconductor Products - Thyristors - SCRs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Voltage - Off State | 1.2 kV |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5 V |
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - On State (It (AV)) (Max) | 70 A |
| Current - Hold (Ih) (Max) | 200 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 1400A @ 50Hz |
| SCR Type | Standard Recovery |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-274AA |
| Supplier Device Package | SUPER-247™ (TO-274AA) |
| Voltage - On State (Vtm) (Max) | 1.4 V |
| Current - On State (It (RMS)) (Max) | 75 A |
| Current - Off State (Max) | 1 mA |
| Base Product Number | 70TPS12 |
| Product Attribute |  |
 |
 |
 |
| Part Number | VS-70TPS12P-S1 | VS-70TPS16PBF | VS-ST180S08P1V | VS-ST1230C16K0P |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | VS-70TPS12P-S1 | SCR 1.6KV 75A SUPER-247 | SCR 800V 314A TO209AB | SCR 1.6KV 3200A A24 |
| Series | - | - | - | - |
| Packaging | Bulk | Tube | Bulk | Bulk |
