VS-U5FH120EA120
Manufacturer
VishayDescription
DIODE MODULE GP 1200V 60A SOT227
Datasheet
DatasheetPackage
SOT-227-4, miniBLOC
In Stock
10,933 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
VS-U5FH120EA120
VS-U5FH120EA120
lmages are for reference only.Payment Methods
Delivery Services
Diode Array 2 Independent 1200 V 60A Chassis Mount SOT-227-4, miniBLOC
Quick Inquiry
VS-U5FH120EA120
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Vishay |
| Series | - |
| Packaging | Strip |
| RoHS Status | |
| Diode Configuration | 2 Independent |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Current - Average Rectified (Io) (per Diode) | 60A |
| Voltage - Forward (Vf) (Max) @ If | 2.5 V @ 60 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 80 µA @ 1200 V |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Mounting Type | Chassis Mount |
| Package / Case | SOT-227-4, miniBLOC |
| Supplier Device Package | SOT-227 |
| Base Product Number | - |
| Reverse Recovery Time (trr) | 71 ns |
| Grade | - |
| Qualification | - |
