WCL3225-471-R
lmages are for reference only.WCL3225-471-R
FIXED IND 470UH 40MA 22.5OHM SMD
Datasheet1210 (3225 Metric)
80,879 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
470 µH Unshielded Drum Core, Wirewound Inductor 40 mA 22.5Ohm Max 1210 (3225 Metric)
WCL3225-471-R
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | WCL3225 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ceramic |
| Inductance | 470 µH |
| Tolerance | ±5% |
| Current Rating (Amps) | 40 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 22.5Ohm Max |
| Q @ Freq | 8 @ 796kHz |
| Frequency - Self Resonant | 2MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 796 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) |
| Supplier Device Package | 1210 |
| Size / Dimension | 0.138" L x 0.114" W (3.50mm x 2.90mm) |
| Height - Seated (Max) | 0.089" (2.25mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | WCL3225-470-R | WCL3225-100-R | WCL3225-101-R | WCL3225-120-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | RoHS Compliant | RoHS Compliant | ||
| Description | FIXED IND 47UH 140MA 5.2 OHM SMD | FIXED IND 10UH 300MA 1 OHM SMD | FIXED IND 100UH 95MA 6.8 OHM SMD | FIXED IND 12UH 265MA 1.2 OHM SMD |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
