WCLA1005V1-470-R
lmages are for reference only.WCLA1005V1-470-R
FIXED IND 47NH 150MA 830MOHM SMD
Datasheet0402 (1005 Metric)
80,329 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
47 nH Unshielded Wirewound Inductor 150 mA 830mOhm Max 0402 (1005 Metric)
WCLA1005V1-470-R
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | WCLA1005V1 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 47 nH |
| Tolerance | ±5% |
| Current Rating (Amps) | 150 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 830mOhm Max |
| Q @ Freq | 25 @ 250MHz |
| Frequency - Self Resonant | 2.1GHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 250 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1005 Metric) |
| Supplier Device Package | 0402 |
| Size / Dimension | 0.047" L x 0.026" W (1.19mm x 0.66mm) |
| Height - Seated (Max) | 0.024" (0.60mm) |
| Base Product Number | - |
| Product Attribute | |
 |
 |
|
| Part Number | WCLA1005V1-100-R | WCLA1005V1-101-R | WCLA1005V1-110-R | WCLA1005V1-110-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 10NH 480MA 200MOHM SMD | FIXED IND 100NH 30MA 2 OHM SMD | FIXED IND 11NH 640MA 120MOHM SMD | FIXED IND 11NH 640MA 120MOHM SMD |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
