WP154A4QBESEGZGC/CA
lmages are for reference only.WP154A4QBESEGZGC/CA
LED BLUE/GRN/ORG CLR T-1 3/4 T/H
DatasheetRadial - 4 Leads
87,607 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Blue, Green, Orange 470nm Blue, 525nm Green, 625nm Orange LED Indication - Discrete 3.3V Blue, 3.3V Green, 1.9V Orange Radial - 4 Leads
WP154A4QBESEGZGC/CA
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Kingbright |
| Series | - |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Color | Blue, Green, Orange |
| Configuration | Common Anode |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 950mcd Blue, 2000mcd Green, 150mcd Orange |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
| Voltage - Forward (Vf) (Typ) | 3.3V Blue, 3.3V Green, 1.9V Orange |
| Current - Test | 20mA Blue, 20mA Green, 20mA Orange |
| Viewing Angle | 50° |
| Mounting Type | Through Hole |
| Wavelength - Dominant | 470nm Blue, 525nm Green, 625nm Orange |
| Wavelength - Peak | 468nm Blue, 515nm Green, 630nm Orange |
| Features | - |
| Package / Case | Radial - 4 Leads |
| Supplier Device Package | T-1 3/4 |
| Size / Dimension | 5.00mm Dia |
| Height (Max) | 8.60mm |
| Base Product Number | WP154 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | WP1503CGDK | WP1503EC | WP1503GC | WP1503GD |
| Manufacturer | Kingbright | Kingbright | Kingbright | Kingbright |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED GREEN DIFFUSED T-1 3/4 T/H | LED RED CLEAR T-1 3/4 T/H | LED GREEN CLEAR T-1 3/4 T/H | LED GREEN DIFFUSED T-1 3/4 T/H |
| Series | Kingbright | Kingbright | Kingbright | Kingbright |
| Packaging | Bulk | Bulk | Bulk | Bulk |
