XMC1403Q064X0064AAXUMA1
lmages are for reference only.XMC1403Q064X0064AAXUMA1
IC MCU 32BIT 64KB FLASH 64VQFN
Datasheet64-VFQFN Exposed Pad
68,562 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M0 XMC1000 Microcontroller IC 32-Bit Single-Core 48MHz 64KB (64K x 8) FLASH PG-VQFN-64-6
XMC1403Q064X0064AAXUMA1
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Infineon Technologies |
| Series | XMC1000 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Core Processor | ARM® Cortex®-M0 |
| Core Size | 32-Bit Single-Core |
| Speed | 48MHz |
| Connectivity | CANbus, I2C, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, I2S, POR, PWM, WDT |
| Number of I/O | 48 |
| Program Memory Size | 64KB (64K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Data Converters | A/D 12x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-VQFN-64-6 |
| Package / Case | 64-VFQFN Exposed Pad |
| Base Product Number | XMC1403 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | XMC1403Q064X0128AAXUMA1 | XMC1403Q064X0200AAXUMA1 | XMC1403Q040X0064AAXUMA1 | XMC1403Q040X0128AAXUMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 32BIT 128KB FLASH 64VQFN | IC MCU 32BIT 200KB FLASH 64VQFN | IC MCU 32BIT 64KB FLASH 40VQFN | IC MCU 32BIT 128KB FLASH 40VQFN |
| Series | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
