Y0094V0001AA0L
lmages are for reference only.Y0094V0001AA0L
RES NETWORK 2 RES 10K OHM RADIAL
DatasheetRadial - 3 Leads
64,122 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
10k Ohm ±0.05% 100mW Power Per Element Voltage Divider 2 Resistor Network/Array ±8ppm/°C Radial - 3 Leads
Y0094V0001AA0L
| Category | Resistors - Resistor Networks-Arrays - |
| Manufacturer | VPG Foil Resistors |
| Series | VSR144 |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Circuit Type | Voltage Divider |
| Resistance (Ohms) | 10k |
| Tolerance | ±0.05% |
| Number of Resistors | 2 |
| Resistor Matching Ratio | ±0.05% |
| Resistor-Ratio-Drift | ±1.5ppm/°C |
| Number of Pins | 3 |
| Power Per Element | 100mW |
| Temperature Coefficient | ±8ppm/°C |
| Operating Temperature | -55°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Applications | Voltage Divider (TCR Matched) |
| Mounting Type | Through Hole |
| Package / Case | Radial - 3 Leads |
| Supplier Device Package | - |
| Size / Dimension | 0.295" L x 0.100" W (7.49mm x 2.54mm) |
| Height - Seated (Max) | 0.320" (8.13mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | Y0094V0001BB0L | Y0094V0001BB9L | Y0094V0001FA9L | Y0094V0001FB9L |
| Manufacturer | VPG Foil Resistors | VPG Foil Resistors | VPG Foil Resistors | VPG Foil Resistors |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES NETWORK 2 RES 10K OHM RADIAL | RES NETWORK 2 RES 10K OHM RADIAL | RES NETWORK 2 RES 10K OHM RADIAL | RES NETWORK 2 RES 10K OHM RADIAL |
| Series | VSR144 | VSR144 | VSR144 | VSR144 |
| Packaging | Bulk | Bulk | Bulk | Bulk |
