TRANS NPN DARL 120V 1A SOT-23F
DatasheetSOT-23-3 Flat Leads
17,906 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN - Darlington 120 V 1 A 120MHz 1.5 W Surface Mount SOT-23F
ZXTN04120HFFTA
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | NPN - Darlington |
| Current - Collector (Ic) (Max) | 1 A |
| Voltage - Collector Emitter Breakdown (Max) | 120 V |
| Vce Saturation (Max) @ Ib, Ic | 1.5V @ 5mA, 2A |
| Current - Collector Cutoff (Max) | 10µA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 3000 @ 1A, 5V |
| Power - Max | 1.5 W |
| Frequency - Transition | 120MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-3 Flat Leads |
| Supplier Device Package | SOT-23F |
| Base Product Number | ZXTN04120 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | ZXTN04120HKTC | ZXTN04120HP5TC | ZXTN07012EFFTA | ZXTN07045EFFTA |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRANS NPN DARL 120V 1.5A TO252-3 | TRANS NPN DARL 120V 1.5A PWRDI5 | TRANS NPN 12V 4.5A SOT-23F | TRANS NPN 45V 4A SOT-23F |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
