40IMX4-1515-8G
lmages are for reference only.40IMX4-1515-8G
DC DC CONVERTER +/-15V 4.2W
Datasheet24-DIP Module, 13 Leads
37,683 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module, Conformal Coated DC DC Converter 2 Output 15V -15V 140mA, 140mA 16.8V - 75V Input
40IMX4-1515-8G
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Bel Power Solutions |
| Series | Melcher IMX4 (4W) |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module, Conformal Coated |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 16.8V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 15V |
| Voltage - Output 2 | -15V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 140mA, 140mA |
| Power (Watts) | 4.2 W |
| Applications | ITE (Commercial), Railway |
| Features | OCP, OTP, OVP, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 82% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 24-DIP Module, 13 Leads |
| Size / Dimension | 1.30" L x 0.79" W x 0.33" H (33.0mm x 20.1mm x 8.4mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | 40IMX4 |
| Voltage - Isolation | 2 kV |
| Product Attribute |  |
 |
 |
|
