74LVC74ABQ-Q100X
lmages are for reference only.74LVC74ABQ-Q100X
IC FF D-TYPE DUAL 1BIT 14DHVQFN
Datasheet14-VFQFN Exposed Pad
69,177 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-VFQFN Exposed Pad
74LVC74ABQ-Q100X
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Nexperia USA Inc. |
| Series | 74LVC |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Function | Set(Preset) and Reset |
| Type | D-Type |
| Output Type | Complementary |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Clock Frequency | 150 MHz |
| Max Propagation Delay @ V, Max CL | 5.2ns @ 3.3V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 1.2V ~ 3.6V |
| Current - Quiescent (Iq) | 10 µA |
| Input Capacitance | 4 pF |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-DHVQFN (2.5x3) |
| Package / Case | 14-VFQFN Exposed Pad |
| Base Product Number | 74LVC74 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute |  |
|
 |
|
| Part Number | 74LVC74ABQ,115 | 74LVC74ABQ,115 | 74LVC74AD,112 | 74LVC74AD,112 |
| Manufacturer | NXP Semiconductors | Nexperia USA Inc. | Nexperia USA Inc. | NXP Semiconductors |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC FF D-TYPE DUAL 1BIT 14DHVQFN | IC FF D-TYPE DUAL 1BIT 14DHVQFN | IC FF D-TYPE DUAL 1BIT 14SO | IC FF D-TYPE DUAL 1BIT 14SO |
| Series | 74LVC | 74LVC | 74LVC | 74LVC |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT)--> | Tube | Bulk |
