APT53F80J
lmages are for reference only.APT53F80J
MOSFET N-CH 800V 57A ISOTOP
DatasheetSOT-227-4, miniBLOC
52,271 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 800 V 57A (Tc) 960W (Tc) Chassis Mount ISOTOP®
APT53F80J
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microchip Technology |
| Series | POWER MOS 8™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 800 V |
| Current - Continuous Drain (Id) @ 25°C | 57A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 110mOhm @ 43A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 5mA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 17550 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 960W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Supplier Device Package | ISOTOP® |
| Package / Case | SOT-227-4, miniBLOC |
| Base Product Number | APT53F80 |
| Gate Charge (Qg) (Max) @ Vgs | 570 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | APT1001R1BN | APT1001R6BFLLG | APT1001RBN | APT1001RBVFRG |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | MOSFET N-CH 1000V 10.5A TO247AD | MOSFET N-CH 1000V 8A TO247 | MOSFET N-CH 1000V 11A TO247AD | MOSFET N-CH 1000V 11A TO247 |
| Series | POWER MOS IV® | POWER MOS 7® | POWER MOS IV® | POWER MOS V® |
| Packaging | Tube | Tube | Tube | Tube |
