BSC014N04LSTATMA1
lmages are for reference only.BSC014N04LSTATMA1
MOSFET N-CH 40V 33A/100A TDSON
Datasheet8-PowerTDFN
42,161 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 40 V 33A (Ta), 100A (Tc) 3W (Ta), 115W (Tc) Surface Mount PG-TDSON-8 FL
BSC014N04LSTATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 33A (Ta), 100A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 1.4mOhm @ 50A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 6020 pF @ 20 V |
| FET Feature | - |
| Power Dissipation (Max) | 3W (Ta), 115W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TDSON-8 FL |
| Package / Case | 8-PowerTDFN |
| Base Product Number | BSC014 |
| Gate Charge (Qg) (Max) @ Vgs | 85 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BSC014N04LSATMA1 | BSC014N04LSIATMA1 | BSC014N03LSGATMA1 | BSC014N03MSGATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 40V 32/100A SUPERSO8 | MOSFET N-CH 40V 31A/100A TDSON | MOSFET N-CH 30V 34A/100A TDSON | MOSFET N-CH 30V 30A/100A TDSON |
| Series | OptiMOS™ | OptiMOS™ | OptiMOS™ | OptiMOS™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
