IGBT Field Stop 650 V 60 A 300 W Through Hole TO-3PN
FGA30N65SMD
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 60 A |
| Current - Collector Pulsed (Icm) | 90 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 30A |
| Power - Max | 300 W |
| Switching Energy | 716µJ (on), 208µJ (off) |
| Input Type | Standard |
| Gate Charge | 87 nC |
| Td (on/off) @ 25°C | 14ns/102ns |
| Test Condition | 400V, 30A, 6Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-3P-3, SC-65-3 |
| Supplier Device Package | TO-3PN |
| Reverse Recovery Time (trr) | 35 ns |
| Base Product Number | FGA30N65 |
| Product Attribute |  |
|
|
 |
| Part Number | FGA30N65SMD | FGA3060ADF | FGA30N120FTDTU | FGA30N60LSDTU |
| Manufacturer | onsemi | onsemi | onsemi | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT FIELD STOP 650V 60A TO3PN | IGBT TRENCH/FS 600V 60A TO3PN | IGBT 1200V 60A 339W TO3P | INSULATED GATE BIPOLAR TRANSISTO |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Bulk |
