FQPF7N10L
lmages are for reference only.FQPF7N10L
MOSFET N-CH 100V 5.5A TO220F
DatasheetTO-220-3 Full Pack
96,490 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 100 V 5.5A (Tc) 23W (Tc) Through Hole TO-220F-3
FQPF7N10L
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Fairchild Semiconductor |
| Series | QFET® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 5V, 10V |
| Rds On (Max) @ Id, Vgs | 350mOhm @ 2.75A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 290 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 23W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220F-3 |
| Package / Case | TO-220-3 Full Pack |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 6 nC @ 5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
|
| Part Number | FQPF7N10 | FQPF7N10L | FQPF7N20 | FQPF7N20 |
| Manufacturer | onsemi | onsemi | onsemi | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | |||
| Description | MOSFET N-CH 100V 5.5A TO220F | MOSFET N-CH 100V 5.5A TO220F | MOSFET N-CH 200V 4.8A TO220F | MOSFET N-CH 200V 4.8A TO220F |
| Series | QFET® | QFET® | QFET® | QFET® |
| Packaging | Tube | Tube | Tube | Tube |
