FQPF7P06
lmages are for reference only.FQPF7P06
MOSFET P-CH 60V 5.3A TO220F
DatasheetTO-220-3 Full Pack
72,450 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 60 V 5.3A (Tc) 24W (Tc) Through Hole TO-220F-3
FQPF7P06
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Fairchild Semiconductor |
| Series | QFET® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 5.3A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 410mOhm @ 2.65A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±25V |
| Input Capacitance (Ciss) (Max) @ Vds | 295 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 24W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220F-3 |
| Package / Case | TO-220-3 Full Pack |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 8.2 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | FQPF7P06 | FQPF70N10 | FQPF7N10 | FQPF7N10L |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | |||
| Description | MOSFET P-CH 60V 5.3A TO220F | MOSFET N-CH 100V 35A TO220F | MOSFET N-CH 100V 5.5A TO220F | MOSFET N-CH 100V 5.5A TO220F |
| Series | QFET® | QFET® | QFET® | QFET® |
| Packaging | Tube | Tube | Tube | Tube |
