Product CatalogPart Number
GPA042A100L-ND
Manufacturer
SemiQDescription
IGBT 1000V 60A 463W TO264
Datasheet
DatasheetPackage
TO-264-3, TO-264AA
In Stock
35,036 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
GPA042A100L-ND
GPA042A100L-ND
lmages are for reference only.Payment Methods
Delivery Services
IGBT NPT and Trench 1000 V 60 A 463 W Through Hole TO-264
Quick Inquiry
GPA042A100L-ND
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | SemiQ |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | NPT and Trench |
| Voltage - Collector Emitter Breakdown (Max) | 1000 V |
| Current - Collector (Ic) (Max) | 60 A |
| Current - Collector Pulsed (Icm) | 120 A |
| Vce(on) (Max) @ Vge, Ic | 2.9V @ 15V, 60A |
| Power - Max | 463 W |
| Switching Energy | 13.1mJ (on), 6.3mJ (off) |
| Input Type | Standard |
| Gate Charge | 405 nC |
| Td (on/off) @ 25°C | 230ns/1480ns |
| Test Condition | 600V, 60A, 50Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-264-3, TO-264AA |
| Supplier Device Package | TO-264 |
| Reverse Recovery Time (trr) | 465 ns |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | GPA015A120MN-ND | GPA020A135MN-FD | GPA025A120MN-ND | GPA030A135MN-FDR |
| Manufacturer | SemiQ | SemiQ | SemiQ | SemiQ |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT 1200V 30A 212W TO3PN | IGBT 1350V 40A 223W TO3PN | IGBT 1200V 50A 312W TO3PN | IGBT 1350V 60A 329W TO3PN |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
