IXGA42N30C3
lmages are for reference only.Payment Methods
Delivery Services
IGBT PT 300 V 223 W Surface Mount TO-263AA
IXGA42N30C3
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | IXYS |
| Series | GenX3™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Voltage - Collector Emitter Breakdown (Max) | 300 V |
| Current - Collector (Ic) (Max) | - |
| Current - Collector Pulsed (Icm) | 250 A |
| Vce(on) (Max) @ Vge, Ic | 1.85V @ 15V, 42A |
| Power - Max | 223 W |
| Switching Energy | 120µJ (on), 150µJ (off) |
| Input Type | Standard |
| Gate Charge | 76 nC |
| Td (on/off) @ 25°C | 21ns/113ns |
| Test Condition | 200V, 21A, 10Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263AA |
| Reverse Recovery Time (trr) | - |
| Base Product Number | IXGA42 |
| Product Attribute |  |
 |
 |
 |
| Part Number | IXGA48N60A3 | IXGA48N60A3-TRL | IXGA48N60B3 | IXGA48N60B3-TRL |
| Manufacturer | IXYS | IXYS | IXYS | IXYS |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT 600V 120A 300W TO263AA | IXGA48N60A3 TRL | IGBT 600V 300W TO263AA | IXGA48N60B3 TRL |
| Series | GenX3™ | GenX3™ | GenX3™ | GenX3™ |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR) |
