Product CatalogPart Number
LDFW016732Y22V0E
Manufacturer
Chemi-ConDescription
CMC 7.3MH 16A 2LN TH
Datasheet
DatasheetPackage
Vertical, No Base, 4 PC Pin
In Stock
20,308 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
LDFW016732Y22V0E
LDFW016732Y22V0E
lmages are for reference only.Payment Methods
Delivery Services
7.3 mH @ 100 kHz 2 Line Common Mode Choke Through Hole 16A DCR 7.9mOhm
Quick Inquiry
LDFW016732Y22V0E
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Chemi-Con |
| Series | FW |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 7.3 mH @ 100 kHz |
| Current Rating (Max) | 16A |
| DC Resistance (DCR) (Max) | 7.9mOhm |
| Voltage Rating - DC | 500V |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 130°C |
| Ratings | AEC-Q200 |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 1.693" Dia (43.00mm) |
| Height (Max) | 1.496" (38.00mm) |
| Package / Case | Vertical, No Base, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
