LM2685MTC/NOPB
lmages are for reference only.LM2685MTC/NOPB
IC REG DL CHRPMP/LINEAR 14TSSOP
Datasheet14-TSSOP (0.173", 4.40mm Width)
31,066 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
PMIC - Voltage Regulators - Linear Switching 2 Output Charge Pump (1), Linear (LDO) (1) 130kHz 14-TSSOP
LM2685MTC/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear Switching |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Topology | Charge Pump (1), Linear (LDO) (1) |
| Number of Outputs | 2 |
| Frequency - Switching | 130kHz |
| Voltage/Current - Output 1 | ±5V, 5.7V ~ 13V, 50mA |
| Voltage/Current - Output 2 | 5V, 50mA |
| Voltage/Current - Output 3 | - |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Voltage - Supply | 2.85V ~ 6.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
| Base Product Number | LM2685 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM2685MTCX/NOPB | LM26480QSQ-AA/NOPB | LM26480QSQ-CF/NOPB | LM26480QSQX-8D/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG DL CHRPMP/LINEAR 14TSSOP | IC REG QUAD BUCK/LNR SYNC 24WQFN | IC REG QUAD BUCK/LNR SYNC 24WQFN | IC REG QUAD BUCK/LNR SYNC 24WQFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
