LM2792LD-L
lmages are for reference only.LM2792LD-L
LED DRIVER, 2-SEGMENT PDSO10
Datasheet10-WFDFN Exposed Pad
48,977 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 2 Output DC DC Regulator Switched Capacitor (Charge Pump) Analog, PWM Dimming 34mA 10-WSON (3x3)
LM2792LD-L
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | DC DC Regulator |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 2 |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.8V |
| Voltage - Output | - |
| Current - Output / Channel | 34mA |
| Frequency | 1.1MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-WSON (3x3) |
| Base Product Number | LM2792 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | LM2792LD-H/NOPB | LM2792LD-L/NOPB | LM2792LD-L/NOPB | LM2792LDX-L/NOPB |
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV RGLTR PWM 34MA 10WSON | IC LED DRV RGLTR PWM 34MA 10WSON | IC LED DRV RGLTR PWM 34MA 10WSON | IC LED DRV RGLTR PWM 34MA 10WSON |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
