LM2794TLX
Manufacturer
National SemiconductorDescription
IC LED DRV RGLTR PWM 20MA 14USMD
Datasheet
DatasheetPackage
14-WFBGA
In Stock
47,496 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
LM2794TLX
LM2794TLX
lmages are for reference only.Payment Methods
Delivery Services
LED Driver IC 4 Output DC DC Regulator Switched Capacitor (Charge Pump) Analog, PWM Dimming 20mA 14-µSMD (2.1x2.4)
Quick Inquiry
LM2794TLX
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | DC DC Regulator |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 4 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | 3.8V |
| Current - Output / Channel | 20mA |
| Frequency | 515kHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 14-WFBGA |
| Supplier Device Package | 14-µSMD (2.1x2.4) |
| Base Product Number | LM2794 |
| Grade | - |
| Qualification | - |
