LTC7840IFE#PBF
lmages are for reference only.LTC7840IFE#PBF
DUAL PHASE/OUTPUT NON-SYNCH BOOS
Datasheet28-TSSOP (0.173", 4.40mm Width) Exposed Pad
73,300 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost Regulator Positive Output Step-Up DC-DC Controller IC 28-TSSOP-EP
LTC7840IFE#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | PWM |
| Function | Step-Up |
| Output Configuration | Positive |
| Topology | Boost |
| Number of Outputs | 2 |
| Output Phases | 2 |
| Voltage - Supply (Vcc/Vdd) | 5.5V ~ 60V |
| Frequency - Switching | 50kHz ~ 425kHz |
| Duty Cycle (Max) | 96% |
| Synchronous Rectifier | No |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Frequency Control, Power Good |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 28-TSSOP-EP |
| Base Product Number | LTC7840 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LTC7840IFE#TRPBF | LTC7840IUFD#PBF | LTC7840IUFD#TRPBF | LTC7800EUDC#PBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DUAL PHASE/OUTPUT NON-SYNCH BOOS | DUAL PHASE/OUTPUT NON-SYNCH BOOS | DUAL PHASE/OUTPUT NON-SYNCH BOOS | IC REG CTRLR SYNC BUCK 60V 20QFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tube |
