PFC2225BNP-702B
lmages are for reference only.PFC2225BNP-702B
CMC 7MH 3A 2LN TH
DatasheetVertical, No Base, 4 PC Pin
91,661 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
7 mH @ 1 kHz 2 Line Common Mode Choke Through Hole 3A DCR 70mOhm
PFC2225BNP-702B
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Sumida America Components Inc. |
| Series | PFC |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 7 mH @ 1 kHz |
| Current Rating (Max) | 3A |
| DC Resistance (DCR) (Max) | 70mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 250V |
| Operating Temperature | -40°C ~ 85°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.984" L x 0.787" W (25.00mm x 20.00mm) |
| Height (Max) | 1.063" (27.00mm) |
| Package / Case | Vertical, No Base, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | PFC2225BNP-702 | PFC2225BNP-152 | PFC2225BNP-402 | PFC2225BNP-451 |
| Manufacturer | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 7MH 2.5A 2LN TH | CMC 1.5MH 5A 2LN TH | CMC 4MH 4A 2LN TH | CMC 450UH 10A 2LN TH |
| Series | PFC | PFC | PFC | PFC |
| Packaging | Bulk | Bulk | Bulk | Bulk |
