800 µH @ 1 kHz 2 Line Common Mode Choke Through Hole 8A DCR 12.5mOhm
PFC2225BNP-801
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Sumida America Components Inc. |
| Series | PFC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Filter Type | - |
| Number of Lines | 2 |
| Inductance @ Frequency | 800 µH @ 1 kHz |
| Current Rating (Max) | 8A |
| DC Resistance (DCR) (Max) | 12.5mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 85°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.984" L x 0.787" W (25.00mm x 20.00mm) |
| Height (Max) | 1.063" (27.00mm) |
| Package / Case | Vertical, No Base, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | PFC2225BNP-152 | PFC2225BNP-402 | PFC2225BNP-451 | PFC2225BNP-502 |
| Manufacturer | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 1.5MH 5A 2LN TH | CMC 4MH 4A 2LN TH | CMC 450UH 10A 2LN TH | CMC 5MH 3A 2LN TH |
| Series | PFC | PFC | PFC | PFC |
| Packaging | Bulk | Bulk | Bulk | Bulk |
