RL3006-50-100-25-PTO
lmages are for reference only.RL3006-50-100-25-PTO
PTC RESET FUSE 25V RADIAL DISC
DatasheetRadial, Disc
61,047 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Ceramic PTC Resettable Fuse 25V Ih Through Hole Radial, Disc
RL3006-50-100-25-PTO
| Category | Circuit Protection - PTC Resettable Fuses - |
| Manufacturer | Amphenol Thermometrics |
| Series | PTO |
| Packaging | Bulk |
| RoHS Status | |
| Type | Ceramic |
| Voltage - Max | 25V |
| Current - Hold (Ih) (Max) | - |
| Current - Trip (It) | - |
| Current - Max | - |
| Resistance - 25°C (Typ) | 50 Ohms |
| Operating Temperature | - |
| Ratings | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Disc |
| Size / Dimension | 0.350" Dia x 0.150" T (8.90mm x 3.80mm) |
| Height - Seated (Max) | 0.350" (8.89mm) |
| Thickness (Max) | - |
| Lead Spacing | 0.250" (6.35mm) |
| Approval Agency | - |
| Time to Trip | 35 s |
| Resistance - Initial (Ri) (Min) | - |
| Resistance - Post Trip (R1) (Max) | - |
| Grade | - |
| Qualification | - |
| Base Product Number | RL3006 |
| Product Attribute |  |
 |
 |
 |
| Part Number | RL3006-50-110-25-PTO | RL3006-50-30-25-PTO | RL3006-50-40-25-PTO | RL3006-50-50-25-PTO |
| Manufacturer | Amphenol Thermometrics | Amphenol Thermometrics | Amphenol Thermometrics | Amphenol Thermometrics |
| RoHS Status | RoHS non-compliant | |||
| Description | PTC RESET FUSE 25V RADIAL DISC | PTC RESET FUSE 25V RADIAL DISC | PTC RESET FUSE 25V RADIAL DISC | PTC RESET FUSE 25V RADIAL DISC |
| Series | PTO | PTO | PTO | PTO |
| Packaging | Bulk | Bulk | Bulk | Bulk |
