SP7685ER-L
lmages are for reference only.SP7685ER-L
IC LED DRVR RGLTR PWM 1.2A 10DFN
Datasheet10-VFDFN Exposed Pad
28,377 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output DC DC Regulator Switched Capacitor (Charge Pump) PWM Dimming 1.2A (Flash) 10-DFN (3x3)
SP7685ER-L
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | MaxLinear, Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Type | DC DC Regulator |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 1.2A (Flash) |
| Frequency | 2.4MHz |
| Dimming | PWM |
| Applications | Backlight, Camera Flash |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-VFDFN Exposed Pad |
| Supplier Device Package | 10-DFN (3x3) |
| Base Product Number | SP7685 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SP7685ER-L/MTR | SP7685ER-L/TR | SP7600EN2-L | SP7600EN2-L/TR |
| Manufacturer | MaxLinear, Inc. | MaxLinear, Inc. | MaxLinear, Inc. | MaxLinear, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | ||
| Description | IC LED DRIVER 10DFN | IC LED DRVR RGLTR PWM 1.2A 10DFN | IC LED DRVR RGLTR PWM 2A 8HSOIC | IC LED DRVR RGLTR PWM 2A 8HSOIC |
| Series | * | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR) |
