Product CatalogPart Number
TNPW060384K5BETA
Manufacturer
Vishay DaleDescription
RES 84.5K OHM 0.1% 1/10W 0603
Datasheet
DatasheetPackage
0603 (1608 Metric)
In Stock
20,488 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
TNPW060384K5BETA
TNPW060384K5BETA
lmages are for reference only.Payment Methods
Delivery Services
84.5 kOhms ±0.1% 0.1W, 1/10W Chip Resistor 0603 (1608 Metric) Military Thin Film
Quick Inquiry
TNPW060384K5BETA
Specifications
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | Vishay Dale |
| Series | TNPW |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Resistance | 84.5 kOhms |
| Tolerance | ±0.1% |
| Power (Watts) | 0.1W, 1/10W |
| Composition | Thin Film |
| Features | Military |
| Temperature Coefficient | ±25ppm/°C |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | 0603 (1608 Metric) |
| Supplier Device Package | 0603 |
| Ratings | - |
| Size / Dimension | 0.063" L x 0.033" W (1.60mm x 0.85mm) |
| Height - Seated (Max) | 0.022" (0.55mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | TNPW0603 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | TNPW060384K5BECN | TNPW060384K5BEEA | TNPW060384K5BEEN | TNPW060384K5BHEA |
| Manufacturer | Vishay Dale | Vishay Dale | Vishay Dale | Vishay Dale |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES 84.5K OHM 0.1% 1/10W 0603 | RES 84.5K OHM 0.1% 0.21W 0603 | RES 84.5K OHM 0.1% 0.21W 0603 | RES 84.5K OHM 0.1% 0.21W 0603 |
| Series | Vishay Dale | Vishay Dale | Vishay Dale | |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
