TS10KL100H
lmages are for reference only.TS10KL100H
10A, 1000V, STANDARD BRIDGE RECT
Datasheet4-SIP, KBJL
45,205 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bridge Rectifier Single Phase Standard 1 kV Through Hole KBJL
TS10KL100H
| Category | Discrete Semiconductor Products - Diodes - Bridge Rectifiers |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 1 kV |
| Current - Average Rectified (Io) | 10 A |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 5 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 1000 V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP, KBJL |
| Supplier Device Package | KBJL |
| Base Product Number | TS10KL100 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | TS10KL100 | TS10K100 | TS10K100H | TS10K40 |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | |||
| Description | BRIDGE RECT 1PHASE 1KV 10A KBJL | 10A, 1000V, STANDARD BRIDGE RECT | 10A, 1000V, STANDARD BRIDGE RECT | 10A, 400V, STANDARD BRIDGE RECTI |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
