UCC27301AQDDARQ1
lmages are for reference only.UCC27301AQDDARQ1
AUTOMOTIVE 120V 4A HALF-BRIDGE D
Datasheet8-PowerSOIC (0.154", 3.90mm Width)
94,844 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 8-SO PowerPad
UCC27301AQDDARQ1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 1 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 8V ~ 17V |
| Logic Voltage - VIL, VIH | 1.9V, 1.7V |
| Current - Peak Output (Source, Sink) | 3.7A, 4.5A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 120 V |
| Rise / Fall Time (Typ) | 270ns, 160ns |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerSOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SO PowerPad |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute |  |
 |
 |
 |
| Part Number | UCC27301AQDRCRQ1 | UCC27301ADR | UCC27301ADRCR | UCC27311ADRCR |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | |||
| Description | AUTOMOTIVE 120V 4A HALF-BRIDGE D | 120V 4A HALF-BRIDGE DRIVER WITH | 120V 4A HALF-BRIDGE DRIVER WITH | 120V 4A HALF-BRIDGE DRIVER WITH |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
