MLF2012DR33JT000
lmages are for reference only.MLF2012DR33JT000
FIXED IND 330NH 250MA 400MOHM SM
Datasheet0805 (2012 Metric)
23,932 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
330 nH Shielded Multilayer Inductor 250 mA 400mOhm Max 0805 (2012 Metric)
MLF2012DR33JT000
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TDK Corporation |
| Series | MLF |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Multilayer |
| Material - Core | Ferrite |
| Inductance | 330 nH |
| Tolerance | ±5% |
| Current Rating (Amps) | 250 mA |
| Current - Saturation (Isat) | - |
| Shielding | Shielded |
| DC Resistance (DCR) | 400mOhm Max |
| Q @ Freq | 20 @ 25MHz |
| Frequency - Self Resonant | 200MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 25 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 (2012 Metric) |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height - Seated (Max) | 0.041" (1.05mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MLF2012DR33JTD25 | MLF2012DR33KT000 | MLF2012DR33KTD25 | MLF2012DR33MT |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 330NH 250MA 400MOHM SM | FIXED IND 330NH 250MA 400MOHM SM | FIXED IND 330NH 250MA 400MOHM SM | FIXED IND 330NH 250MA 400MOHM SM |
| Series | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
