ZL30261LDF1
lmages are for reference only.ZL30261LDF1
IC CLOCK MULTIPLIER 56QFN
Datasheet56-VFQFN Exposed Pad
46,287 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Clock Multiplier, Frequency Synthesizer IC 1.045GHz 1 56-VFQFN Exposed Pad
ZL30261LDF1
| Category | Integrated Circuits (ICs) - Clock-Timing - Clock Generators-PLLs-Frequency Synthesizers |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | ZL30261 |
| Type | Clock Multiplier, Frequency Synthesizer |
| PLL | Yes with Bypass |
| Input | CMOS, Crystal |
| Output | CMOS, HCSL, HSTL, LVDS, LVPECL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 4:6 |
| Differential - Input:Output | Yes/Yes |
| Frequency - Max | 1.045GHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 1.71V ~ 3.465V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 56-VFQFN Exposed Pad |
| Supplier Device Package | 56-QFN (8x8) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ZL30261LDG1 | ZL30244LFF7 | ZL30244LFG7 | ZL30245LFF7 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC CLOCK MULTIPLIER 56QFN | IC CLOCK MULTIPLIER 64LGA | IC CLOCK MULTIPLIER 64LGA | IC CLOCK MULTIPLIER 64LGA |
| Series | - | - | - | - |
| Packaging | Tray | Tape & Reel (TR)-->Cut Tape (CT) | Tray | Tape & Reel (TR) |
