4.7 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 700mA DCR 440mOhm (Typ)
B82791G2701N001
| Category | Filters - Common Mode Chokes - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B82791 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 4.7 mH @ 10 kHz |
| Current Rating (Max) | 700mA |
| DC Resistance (DCR) (Max) | 440mOhm (Typ) |
| Voltage Rating - DC | 80V |
| Voltage Rating - AC | 42V |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | ENEC, UR, VDE |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.689" L x 0.689" W (17.50mm x 17.50mm) |
| Height (Max) | 0.315" (8.00mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | B82790C0105N240 | B82790C0113N201 | B82790C0225N265 | B82790C0253N201 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 1MH 500MA 2LN SMD AEC-Q200 | CMC 11UH 500MA 2LN SMD AEC-Q200 | CMC 2.2MH 400MA 2LN SMD AEC-Q200 | CMC 25UH 500MA 2LN SMD AEC-Q200 |
| Series | B82790 | B82790 | B82790 | B82790 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
