CLF10040T-2R2N-CA
lmages are for reference only.CLF10040T-2R2N-CA
FIXED IND 2.2UH 5A 12.61MOHM SMD
DatasheetNonstandard
28,704 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.2 µH Shielded Drum Core, Wirewound Inductor 5 A 12.61mOhm Max Nonstandard
CLF10040T-2R2N-CA
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TDK Corporation |
| Series | CLF-CA |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 2.2 µH |
| Tolerance | ±30% |
| Current Rating (Amps) | 5 A |
| Current - Saturation (Isat) | 7.5A |
| Shielding | Shielded |
| DC Resistance (DCR) | 12.61mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 105°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.394" L x 0.382" W (10.00mm x 9.70mm) |
| Height - Seated (Max) | 0.161" (4.10mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
|
| Part Number | CLF10040T-2R2N | CLF10040T-2R2N | CLF10040T-2R2N-D | CLF10040T-2R2N-D |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | FIXED IND 2.2UH 5A 12.61MOHM SMD | FIXED IND 2.2UH 5A 12.61MOHM SMD | FIXED IND 2.2UH 5A 12.61MOHM SMD | FIXED IND 2.2UH 5A 12.61MOHM SMD |
| Series | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
